Robust and Agile: 120KW EV Chassis with 0-2500RPM Speed Range
Robust and Agile: 120KW EV Chassis with 0-2500RPM Speed Range
Product Name: Electric Vehicle Chassis
Motor type: permanent magnet synchronous motor
Front axle: Disc type, 6.5 tons
Rear axle: disc type, 11.5 tons
Suspension: Front 2, Rear 4 Air Suspension
Braking form: Front and rear disc dual circuit driving air brake, manual valve type energy storage spring brake, driving motor regenerative auxiliary brake
Rated power: 120KW
Speed range: 0~2500r/min
Introducing the Heavy-Duty Electric Vehicle Chassis: Unmatched Strength and Versatility
Meet the pinnacle of robustness and innovation with our electric vehicle chassis, meticulously designed for the demands of heavy-duty applications. Powered by a permanent magnet synchronous motor, this chassis offers a rated power of 120KW, ensuring relentless performance and smooth operation across various terrains.
The chassis boasts an impressive disc type front axle with a 6.5-ton capacity and a disc type rear axle capable of supporting 11.5 tons, making it an ideal choice for heavy load transportation. The front 2 and rear 4 air suspension system provides superior comfort and control, adapting to the road conditions for a stable ride.
Safety and stopping power are paramount with our front and rear disc dual circuit driving air brake, complemented by a manual valve type energy storage spring brake and driving motor regenerative auxiliary brake, ensuring reliable and efficient braking even in the most challenging situations.
Designed for versatility, the chassis operates over a speed range of 0 to 2500r/min, catering to a wide array of electric vehicle requirements.
Key Highlights:
- High-rated power for heavy-duty performance.
- Massive load-bearing capacity with robust axles.
- Advanced air suspension for optimal comfort and control.
- Multi-level braking system for enhanced safety.
- Versatile speed range for diverse applications.
This chassis is more than a foundation; it’s the powerhouse of your next electric vehicle project. For further inquiries or to discuss your specific needs, contact us today. Let’s drive the future of electric mobility together.
