VDO 15bar Brake Pressure Gauge Black 52Mm 2 1/16in A2C3833450001
A2C3832960001 A2C3832910001 A2C3832960001 -40°C to +80°C 80mm/85mm Speedometer
VDO 15bar Brake Pressure Gauge Black 52Mm 2 1/16in A2C3833450001
Part NO. : A2C3833450001 A2C3833450001 A2C3832710001 A2C3833480001 A2C3832730001
Temperature Range: -40°C to +80°C
Brand: VDO
Quality: Genuine Quality
VDO 15bar Brake Pressure Gauge Black 52Mm 2 1/16in A2C3833450001
OTHER PART NUMBER:
| Individually package | Large package (10 pieces) | After-sales package | Backlight color | Rang(unit) | CAN |
| A2C3833450001 | A2C3833450025 | A2C3833450030 | WHITE | 0-10bar | 65274 117 0x25 |
| A2C3832710001 | A2C3832710025 | A2C3832710030 | WHITE | 0-16bar | 65274 117 0x25 |
| A2C3833480001 | A2C3833480025 | A2C3833480030 | WHITE | 0-150psi | 65274 117 0x25 |
| A2C3832730001 | A2C3832730025 | A2C3832730030 | WHITE | 0-250psi | 65274 117 0x25 |
| A2C3833450031 | AMBER | 0-10bar | 65274 117 0x25 | ||
| A2C3832710031 | AMBER | 0-16bar | 65274 117 0x25 | ||
| A2C3833480031 | AMBER | 0-150psi | 65274 117 0x25 | ||
| A2C3832730031 | AMBER | 0-250psi | 65274 117 0x25 | ||
| A2C3833450032 | RED | 0-10bar | 65274 117 0x25 | ||
| A2C3832710032 | RED | 0-16bar | 65274 117 0x25 | ||
| A2C3833480032 | RED | 0-150psi | 65274 117 0x25 | ||
| A2C3832730032 | RED | 0-250psi | 65274 117 0x25 | ||
| A2C3833450033 | GREEN | 0-10bar | 65274 117 0x25 | ||
| A2C3832710033 | GREEN | 0-16bar | 65274 117 0x25 | ||
| A2C3833480033 | GREEN | 0-150psi | 65274 117 0x25 | ||
| A2C3832730033 | GREEN | 0-250psi | 65274 117 0x25 | ||
| A2C3833450034 | BLUE | 0-10bar | 65274 117 0x25 | ||
| A2C3832710034 | BLUE | 0-16bar | 65274 117 0x25 | ||
| A2C3833480034 | BLUE | 0-150psi | 65274 117 0x25 | ||
| A2C3832730034 | BLUE | 0-250psi | 65274 117 0x25 |
Product Details:
| Input Type: | CAN 1939 or Analog |
| Voltage: | 12/24V |
| Warning light: | Red LED Via plus and min |
| Operating voltage: | 8 – 32 Volt DC |
| Application: | VDO Engine monitoring |
| Connector type: | Molex 8-Pin CANBus |
| Diameter (US): | 21/16 in |
| Glass: | Anti-fog and anti-reflective glass |
| Material: | Plastic,Mineral Glass (outer lens)Plastic (inner lens) |
| Protection level: | IP 67 |
| Working temperature: | -40°C to +80°C |
VDO 15bar Brake Pressure Gauge Black 52Mm 2 1/16in A2C3833450001 A2C3833450001 A2C3832710001 A2C3833480001 A2C3832730001
VDO 15bar Brake Pressure Gauge Black 52Mm 2 1/16in A2C3833450001 A2C3833450001 A2C3832710001 A2C3833480001 A2C3832730001
- Black – Hole: 52 mm – 2 1/16″
- Operating voltage: 8-32 Volt DC
- Range: 0 – 25 Bar – ISO 1167
- Analogue signal: 10 – 184 Ohm
- CANBus input: 65272 – 127 – 0x23
- Connection cable order separately
- HS Code: 85122000
- Ean Code: 4103590679543
- Weight: 0.14kg
